Three-phase wet & dry
T22 L100 L GV CC
Product number: 4030500475
2,2 kW, tailored for metal production
_MD-ps-Original-CNEPLF.webp?width=768&rxy=0.5%2c0.5&format=webp)
_MD-ps-Original-CNEPNJ.webp?width=768&rxy=0.5%2c0.5&format=webp)
_MD-ps-Original-CNEPLF.webp?width=768&height=768&rxy=0.5%2c0.5&format=webp)
_MD-ps-Original-CNEPNJ.webp?width=768&height=768&rxy=0.5%2c0.5&format=webp)
T22 L100 L GV CC
Model T22 is a threephase industrial vacuum for wet and dry material.
Brochures & documents for
Download print and video material to learn more
Accessories for T22 L100 L GV CC
Complete range of accessories
Tech install
Filter
ABSOLUTE FILTER KIT T22-T40 T40W-VHC200
Product number: 4056000523
Tech install
Filter
KIT STAR FILTER D460 L CLASS
Product number: 40000338
Tech install
Filter
STAR FILTER KIT D460 M CLASS
Product number: 40000492
Tech install
Hose Vacuum Cleaner
AIR HOSE D40MT3+SLEEVES
Product number: Z7 22049
Tech install
Hose Vacuum Cleaner
AIR HOSE D40MT5+SLEEVES
Product number: Z7 22362
Tech install
-ps-WebsiteLarge-JLNNPLM.jpg)
Hose Vacuum Cleaner
AIR HOSE D50MT3+SLEEVES
Product number: Z7 22062
Tech install
Hose Vacuum Cleaner
AIR HOSE D50MT5+SLEEVES
Product number: Z7 22363
Tech install
Hose Vacuum Cleaner
AIR HOSE D70MT3+SLEEVES
Product number: Z7 22063
Tech install
Hose Vacuum Cleaner
AIR HOSE D70MT5+SLEEVES
Product number: Z7 22364
Specifications for T22 L100 L GV CC
Voltage (V)400
Frequency (Hz)50
IP protection class55
Insulation classI
Rated power (kW)2.2
Airflow without hose (m³/h - l/m) 315 - 5250
Max. vacuum (kPa - mbar)21 - 210
Sound pressure level (dB(A))68
Container capacity (l)100
Main filter typePolyester Star Filter
Main filter area (cm²)19500
Upstream HEPA H14 filter (if present) (cm²) -
Inlet (mm)70
Length x width x height (mm)1130x600x1530
Weight (kg)114
CO2 emissions for “T22 L100 L GV CC”
Estimate your annual CO2 footprint based on weekly usage.
0 kg
CO2 per year
Different variants of T22 L100 L GV CC
Below you can see the different variants of the product
